200Nm Digital Flange Torque Sensor For Engine Transmission Test

Brand Name : SeeLong

Model Number : SLFN-500

Certification : CMC

Place of Origin : Luoyang China

MOQ : 1

Price : USD 2939dollar

Payment Terms : T/T

Supply Ability : 20 pcs per month

Delivery Time : 10-15days

Packaging Details : 300mmF*300mm*200mm wooden box

measuring range : 500Nm

accuracy class : 0.2%

working speed : 0-15000rpm

overload capacity : 120%

response frequency : 500 μ s

lag : <0.1%

relative humidity : <90%RH

Insulation Resistance : ＞200MΩ

Contact Now

200Nm 15000rpm Digital Torque Flange For Engine and Transmission Test

200Nm 15000rpm Digital Torque Flange For Engine and Transmission Test


Torque sensors

Flanged Torque Sensor adopts the machine's compact flange-flange connection design. One end of the rotor is installed in the transmission end, and the other end is directly connected with the load end, which can be easily installed in the transmission system. In addition, the sensor has a built-in speed measurement unit. Flanged torque sensors can be installed directly on the transmission equipment. The stator ring is fixed on the outer ring of the rotating rotor and supported by the stator base. Sensor volume, dimensions, materials, measurement system and signal transmission are designed specifically for harsh and complex engine test stand conditions.

Product features


  1. 0.2% or 0.5% precision level, optional voltage or frequency signal output
  2. Realize sensor parameter identification, setting, measurement and zero balance through RS-232C interface
  3. Very small axial size
  4. Compact flange-flange connection design
  5. Digital non-contact signal transmission
  6. No bearings, no maintenance
  7. System self-check function​



Technical parameter



Measuring range

0±50N.m ±100N.m ±200N.m ±500N.m ±1000N.m

±2000N.m ±5000N.m ±1 万 N.m

Output signal

5-15KHZ 0-10V 4-20mA

Overload capacity

120%

Accuracy

0.5% 0.2%

Power supply

24VDC

Optimum operating Speed

0-15000 rpm



Response frequency



500μs

Insulation resistance

＞200MΩ

Zero drift



＜0.5%

Repetitive

＜0.1%

Linear

＜0.1%

Lag

＜0.1%

Environment temperature

-40-60℃

Relative humidity

＜90%RH

Temperature range

-10-70℃

Amplitude of transmitter

10V

Storage temperature range

-25-80℃

Transducer power consumption

≈4W

Sensor current consumption

100MA

Sensor shell



Strong anodized aluminum

The response time of the strain gauge dynamic strain wave

3.2X10-6s



Layout

 200Nm Digital Flange Torque Sensor For Engine Transmission Test
